Wellzoom Desktop Extruder Line II
■ Maximum extrusion speed: 4400mm / min(1.75mm, ABS)
■ Suitable materials: ABS, PLA, Nylon, wood plastic, PVA, PS and so on
■ Operating temperature: below 320℃(maximum 450℃ or 600℃ need customizing)
■ Temperature zone: 2 temperature zones (independent control)
■ Temperature control accuracy: ± 1℃
■ Accuracy of filament: 1.75mm, + / – 0.05; 3mm, + / – 0.1
■ Power requirement : 220V, 50Hz (110V, 50Hz need customizing)
■ Power: 220W-440W
■ Nozzle: 2 (1.8mm, 3.2mm)
Wellzoom C extruder：
1.Simple appearance, easy to operate.
3.Easy to clean the material cavity and change the nozzle.
4.Special screw, high efficiency extrusion.
5.Can adapt to most of thermoplastic materials.
6.Can modulate color. It can meet your needs about the color and material of filament.
7.Large-capacity hopper is transparent, you can monitor and add material easily.
8.Dual-zone & independent temperature control can meet the requirement better to composite material.Preheat zone is for melting materials.Extrusion zone is for controlling extrusion temperature.
1. Stepping motoris used to ensure stable traction speed.
3.On-line measurement function.
4. A variety of cooling combinations can be chosen.We can provide the best solution.
1.Match the extrusion speed of the extruder automatically.
2.The traverse mechanism can arrange the filament in order.
3.The traverse range can be adjusted to adapt to different reels.
4.Reel speed can be adjusted.
Click to buy Wellzoom Desktop Extruder Line II+ (450℃)
